Monday, September 21, 2015

QR tracking using the Parrot Jumping Sumo camera

Nested QR code with the Sumo's wheels against the monitor.
To implement "auto-docking" I am intending to use a 7x7cm square nested QR code target and the Sumo's FPV camera. The QR nesting allows detection and recognition at distances up to 50cm whilst remaining accurate right up the moment of touching the docking station. The pictures shown here are actual snapshots from my Jumping Sumo's FPV camera (640x480 resolution).

Same QR code image at an approx range of 30cm from the monitor.
I've prototyped some detection code using an install of the python-qrtools package on the Raspberry Pi:

This code successfully recognises the two QR codes in these test images, though it takes about half a second to do so.

Next up, a docking control loop!

Saturday, September 19, 2015

Capturing photos from a Parrot Jumping Sumo using Python


After a slightly faulty first effort I have successfully taken a photo from my Jumping Sumo using Python's telnetlib module.

In the following code the built-in yavta tool is used to push (and buffer) a snapshot from the camera to /dev/stdout and then base64 is used to push an encoded version of /dev/stdout back to the Python client where it is decoded and saved to disk. As before I have to kill the dragon-prog process to gain access to the camera.

There are a number of alternative image capture routes using yavta, e.g. saving the file to the Sumo's flash or a ram disk and using FTP to recover it. This one seems to be the quickest (and simplest) for now and will suffice for the purposes of identifying and homing in on the charging station.

Monday, September 14, 2015

(Almost) taking snapshots over telnet on a Parrot Jumping Sumo

As part of the my attempts to set up inductive charging on a Parrot Jumping Sumo I am looking at some form of "docking" control where when the robot is close to the charging station it attempts to self-dock, using the camera and some sort of marker on the charging station.

To do this I'm going to need to access the video feed and before I go down the path of setting up the full Parrot SDK I thought I'd have a poke around the Sumo's Linux OS internals.

It turns out that the Sumo has yavta - aka "Yet Another V4L2 Test Application".

So, after telnetting to the Sumo on I first needed to stop the Sumo process that was accessing the camera (disclaimer, this is the process that does "everything" that makes the Sumo work with your phone so you'll need to reboot to restore normal functionality):

kill `pidof dragon-prog`

Then I was able to take a snapshot using yavta:

yavta --capture=1 --file=/data/ftp/image.jpeg /dev/video0

To grab that image I simple FTP'd it from - it's waiting in the root of the FTP file tree.

There's only one (not unsolvable, I hope) problem though - the frame wasn't fully captured so only the top couple of rows of pixels had valid data...

Saturday, August 29, 2015

Inductive charging installation test 2

(Warning, more tacky tunes)

I've tidied up the install significantly and switched the RFID tag to be on top of the robot. Previously it was at the front (to be close to the detection coil) but that was obscuring the charging coil and camera. Doing it this way also allows me to play with the balancing mode of the Jumping Sumo.

The charging appears to be very slow though so the next step will be to push the charging coil completely flush to the box to get the closest possible coupling.

Here's a close-up of the neater install (I've since routed the power supplies through a cable gland):

[Instagram] Onboard heading in to charge

Friday, August 28, 2015

RFID-triggered inductive charging a Parrot Jumping Sumo

It works (tacky YouTube music and all)!

Obviously the IKEA box will be replaced with something a little more visually-appealing (and with less masking tape), but the basic RFID detection and charging enablement control loop works perfectly. The code for the Raspberry Pi is on GitHub.

These are the basic components so far:

[Instagram] Wireless robot charging station mock up #maskingtape
